Cadmium-free RoHS 3528 SMD SMT 5 VDC Ambient Photoresistor Light Sensors With Spectrum 450-1050nm

EKPSMD3528 SMD Light Sensor Features

Special filter epoxy coating;
Special response characteristics similar to the human eyes;
Output linearity across wide illumination range
Certain temperature stability;
Low dark current,low intensity of illumination.

Low sensitivity variation across various light sources

Cadmium-free / RoHS compliant / PB free

Typical Applications

Detection of ambient light to control display backlighting

Mobile devices

Mobile phones, PDAs

Computing devices

Notebooks, Webpads

Consumer devices

TVs, Video Cameras, Digital Still Camera

Automatic Residential and Commercial Lighting Management

Electronic Signs and Signals

Customization

1) Complete varieties, short production cycle , small batch inventory

2) Customize different shapes and angles

3) Customize most suitable specifications to make the product be more competitive
