SMT Transient Suppressors Chip Metal Oxide Varistor MVR3220-471G 35pF 450A Clamping 775V Varistor 470V 3220 (8552M) Case

SMT Transient Suppressors Chip Metal Oxide Varistor MVR3220-471G 35pF 450A Clamping 775V Varistor 470V 3220 (8552M) Case

Description

Aolittel MVR Series offers the designer a surface mount solution with higher voltage ratings and transient energy ratings than typical multi-layer varistors (MLVs). Think of this series as surface mountable MOVs. This series, based on our proven zinc oxide formulation, operates from -55ºC to 125ºC. Additionally, the top and bottom surfaces of the chip are protected with a glass coating.

Higher voltage rating and transient energy rating than typical multi-layer ceramic varistors
Proven Zinc Oxide formulation
Top and bottom surfaces glass coated
Radial MOV replacement
Dimensions (mm) : 8.5x5x2

Application

• MOV (Radial) Replacement

• Suppression of transient on line voltage

• Electric Meters

• Industrial Equipment

• Mains PSUs

• Telecommunications

• Consumer Electronics

Size(mm)
